Overall    dimensions

Length

10080mm

Overall    width

2490 mm

Overall    height

2460mm

Work    platform dimensions

Length

2400mm

Width

900mm

Wheelbase

2500mm

Maximum working    height

22m

Maximum    platform height

20m

Maximum    working range

16.6m

Maximum    carrying capacity

300 kg    (Without limit)/ 460 kg (With limit)

Luffing range of boom

-3°~ +73°

Slewing angle of turntable

360°

Tail swing of turntable

1310 mm

Slewing angle of platform

160°

Overall    weight

12460kg

Traveling    speed

6.3 km/h

Minimum    turn radius

6m

Minimum    ground clearance

230mm

Maximum    gradeability

45%

Tire    specification

36×14-20；355/55D625

Engine    model

Kubota V2403-CR-EW02

Engine    rated power

36.8kw/(2700r/min)
